A Flexible and Compact Semicircular Antenna for Multiple Wireless Communication Applications
Arshad F; Tenhunen H; Naqvi SI; Amin Y; Akhtar F
A Flexible and Compact Semicircular Antenna for Multiple Wireless Communication Applications
Arshad F
Tenhunen H
Naqvi SI
Amin Y
Akhtar F
SPOLECNOST PRO RADIOELEKTRONICKE INZENYRSTVI
Julkaisun pysyvä osoite on:
https://urn.fi/URN:NBN:fi-fe2021042719845
https://urn.fi/URN:NBN:fi-fe2021042719845
Tiivistelmä
This work presents a compact, quad-band planar antenna intended for assimilation into flexible and conformal devices. The CPW-fed semicircular shaped prototype with rake-shaped slots is designed, realized and characterized experimentally. The frequency bands covered by the proposed radiator are centered at 2.5, 3.7, 5.5 and 8 GHz with measured impedance bandwidths of 16%, 13.5%, 11.8% and 14.63%, respectively. The proposed antenna is thus enabled to support WLAN, ISM, Bluetooth, WiMAX LTE and X-band applications. The antenna exhibits a significant gain. The radiation characteristics of the proposed radiator are measured in concave and convex bent shapes at various radii to analyze its flexibility. Performance of the antenna remains almost unaffected in the bent situation. Measurements demonstrate good coherence with simulations. The compactness and good performance of the design both in bent and unbent conditions proves it to be the better contender for future multiband conformal wireless applications.
