Hyppää sisältöön
    • Suomeksi
    • In English
  • Suomeksi
  • In English
  • Kirjaudu
Näytä aineisto
  •   Etusivu
  • 3. UTUCris-artikkelit
  • Rinnakkaistallenteet
  • Näytä aineisto
  •   Etusivu
  • 3. UTUCris-artikkelit
  • Rinnakkaistallenteet
  • Näytä aineisto
JavaScript is disabled for your browser. Some features of this site may not work without it.

Tribocorrosion performance of additively manufactured CuNi30 and SS-316L in marine environment: Seawater resistant alloys

Anjum, Muhammad Ammar; Nath, Ananya; Goel, Sneha; Mäkilä, Ermei; Sarkar, Sagar; Salminen, Antti; Ganvir, Ashish

Tribocorrosion performance of additively manufactured CuNi30 and SS-316L in marine environment: Seawater resistant alloys

Anjum, Muhammad Ammar
Nath, Ananya
Goel, Sneha
Mäkilä, Ermei
Sarkar, Sagar
Salminen, Antti
Ganvir, Ashish
Katso/Avaa
1-s2.0-S2238785425027875-main.pdf (18.65Mb)
Lataukset:

Elsevier BV
doi:10.1016/j.jmrt.2025.10.247
URI
https://doi.org/10.1016/j.jmrt.2025.10.247
Näytä kaikki kuvailutiedot
Julkaisun pysyvä osoite on:
https://urn.fi/URN:NBN:fi-fe202601216152
Tiivistelmä

This study presents the first systematic investigation of the tribocorrosion resistance of additively manufactured CuNi30 in artificial seawater (ASTM D1141-98), along with mechanical and tribocorrosion performance comparison against SS-316L. Both alloys were produced by laser powder bed fusion (PBF-LB/M), achieving relative densities of 99.8 % (CuNi30) and 99.1 % (SS-316L). The as-built CuNi30 exhibited a tensile strength of 503 MPa, which increased to 638 MPa after heat treatment at 550 °C for 2 h, reaching parity with SS-316L. Phase identification through X-ray diffraction confirmed the precipitation of Nb-rich precipitates (NbNi3) after heat treatment which contributed to the observed strengthening. The tribocorrosion performance was evaluated using a ball-on-disk setup, where potentiostatic, potentiodynamic, EIS, and COF measurements were recorded under both static and sliding conditions to assess corrosion-wear interactions. The results revelated that SS-316L is more susceptible to tribocorrosion damage due to its lower polarization stability and the formation of thin unstable third body layer. The calculated wear rate showed a decrease from 9.07 × 10−8 mm3/N·mm for SS-316L to 2.08 × 10−8 mm3/N·mm for heat-treated CuNi30, highlighting the superior tribocorrosion resistance of CuNi30.

Kokoelmat
  • Rinnakkaistallenteet [29335]

Turun yliopiston kirjasto | Turun yliopisto
julkaisut@utu.fi | Tietosuoja | Saavutettavuusseloste




Tämä kokoelma

JulkaisuajatTekijätNimekkeetAsiasanatTiedekuntaLaitosOppiaineYhteisöt ja kokoelmat

Omat tiedot

Kirjaudu sisäänRekisteröidy

Turun yliopiston kirjasto | Turun yliopisto
julkaisut@utu.fi | Tietosuoja | Saavutettavuusseloste
